Coded Lock LGF Dome Array Exported Light Guide Film type 30% Click Ratio

Name: Coded Lock LGF Dome Array Exported Light Guide Film type 30 Click Ratio
Brand: Guanghongda
Price: 0.25 USD

Buy cheap Coded Lock LGF Dome Array Exported Light Guide Film type 30% Click Ratio product

Place of Origin : China

Brand Name : Guanghongda

Model Number : GHD194002

Certification : ROHS compliance

MOQ : 500-999 Pieces

Price : $0.25

Application : Telecommunication Equipment

Keypad Button Material : PET

Metal Dome Material : SUS301

Total Height : 0.14~0.5mm

Metal dome Force : 100~600gf , +/-30gf

click ratio : >30%

Lifetime : 300k~ 2kk hits

Salt sprary Chamber Testing Conditions : -40 ~ +70 degrees

Reliable Routine Test : 55+/-2 degrees , R.H. 95% , 48H

Size tolerance : +/-0.1mm

OEM service : acceptable

Selling Units : Single item

Single package size : 10X7X0.2 cm

Single gross weight : 0.100 kg

Package Type : 1) packed by PET bag ( Full package qty : 200 sheet / PET bag ) Carton package, inner 4 -corner wrap by bubble foam prevent from damage during the transporation

Contact Now

Coded Lock LGF Dome Array Exported Light Guide Film type 30% Click Ratio

What is LGF Dome Array and How does it work ?

LGF metal dome array , which full name is Light Guide Film , it is a new design . which used to replace LED in function , in comparsion with LED , lighting Uniformity; When we add a LGF on current normal double layer or EMI dome array, it becomes a LGF dome array. It can achieve great result of light distribution.see from the design , the light under keypad is coming from the LED on PCB motherboard. We need to put about 8-10 pieces LED on each board, but if the design changed to use LGF, then we can save several LED, as well as SMT fee.

Coded Lock LGF Dome Array Exported Light Guide Film type 30% Click Ratio

What is the LGF DESIGN PRINCIPLE & What is the Advantage ?

LGF, at least one surface out of front and rear surfaces of the light guide film is formed with a pattern such that density increases as distanced from a light source to allow light to be uniformly supplied to the keypad, or is concentratively formed with a pattern at a particular region of the light guide film to allow the light to be concentratively supplied to a particular region of the keypad.

Coded Lock LGF Dome Array Exported Light Guide Film type 30% Click Ratio

PRODUCT PHOTOGRAP

Major Technical Parameters & Advantages of Metal Dome Array
Item	Description	TECHNICAL INDEX
1	LONG LIFE-TIME	Round ,Oval, four - legged, triangular, rectangular, three - point side, irregular
		Stainless Steel ,Nickel Plating ,Silver Plating & gold Plating
		Dimple Numbers : 0/1/3/4/5 dimple
		LIFE-TIME : 300 ~3000 Thousand Times
		In compare of initial value , The change rate <30% after 1M press-test
2	Click %	Force:100gf~450gf, Tolerance : ±20gf
2	Click %	Normal Condition
3	Stroke	Customize in accordance with Customer ‘s requirement
3	Stroke	0.12~0.6mm ,Spec. various by different METAL DOME
4	Dimension Tolerance	Position dimension tolerance : + /- 0.1mm
5	Good Weatherproof Resistance	Under the conditions of 55±2℃,R.H.95% , Replacement 24H , and then resume 2H under the normal room temperature
6	Good Corrosion Resistance	High Temperature can bear : +70℃ Lower Temperature can bear : -40℃
7	Tape Adhesive Test	0.6↑(Unit:kgf/inch)
8	Stable Tape Shrinkage rate	MD(%):0.5 ↓ CD(%):0.3 ↓
8	Stable Tape Shrinkage rate	(Unit:100℃*40mins)
9	Small Instantaneous Contact Resistance	(Nickel Plating ) <1Ω, ( Stainless Steel )<3Ω
10	Total Thickness of Base materials	0.05mm,0.075mm,0.1mm,0.125mm,0.15mm; Normal Thickness Spec.
10	Total Thickness of Base materials
11	Light-Guide-film Uniformity	>75%

Coded Lock LGF Dome Array Exported Light Guide Film type 30% Click Ratio

Q1: Are you Trading company or manufacturer ?

A: We are a Professional Trading & Manufacturer Integrated .

Q2 : Can you offer OEM Service ?

A: Surely Okay , we have Seasoned OEM service experience .

Q3: what is the Lead time of sample ?

A : It takes 2-7working days depends .

Q4: How fast can i get the Quotation ?

A: 30mins ~ 24Hours depends .

Please do not hesitate to contact with us , if you have any inquires .
